8kW Pure Sine Wave Off Grid Solar Inverter
3 phase 8kW power rating pure sine wave power inverter is a off grid no battery storage inverter system converts the DC power to AC power, it is useful for areas without electricity, vehicles, ships, solar energy and other renewable energy systems etc.
-
*
-
-
*
-
-
*
-
-
*
-
-
*
-
Features
- Two kinds of start mode: Step-down voltage start and variable frequency start. Customers can set start mode according to the type of their load.
- The output voltage can be set between -40 % to +20 % of rated voltage. And the output voltage is very accuracy ±1%.
- Pure sine wave output. With good dynamic response less than 50MS, waveform distortion rate smaller, higher conversion efficiency and stable output voltage.
- Adopts black pure aluminum radiator, which confirms the best radiating performance.
- Powerful data display function. LCD can display the DC input voltage, output frequency, phase voltage, phase current, AC bypass input voltage, power consumption (kWH), time and date, temperature, fault code display.
- Wide input voltage can work without battery and solar charge controller, save more cost and with MPPT wide voltage input function, maximum use of solar power.
Parameter List
| Model |
ATO-OGI-8kW |
| Size (D*W*H) |
450*550*760mm |
| Weight |
140kg |
| Certificate |
CE, UL, SA, SAA, VDE |
| Warranty period |
12 months |
| AC Input |
Rated voltage |
AC input voltage is the same value as the AC output (optional) |
| DC Input |
Rated voltage |
48V/ 72V/ 96V DC (can be customized) |
| Rated current |
42A @192V DC |
| AC Output |
Rated output power |
8kW |
| Output waveform |
Pure sine wave |
| Rated voltage |
208V/ 220V/ 230V/ 240V/ 380V/ 400V/ 415V/ 460V/ 480V (optional) |
| Phase |
3 phase 4 wire+PE wire (single phase/ split phase can be customized, please contact us by email) |
| Rated phase current |
12A @380V AC |
| Frequency |
50Hz or 60Hz |
| Power factor |
>0.99 |
| Overload ability |
150%, 5 seconds |
| Efficiency |
>93% |
| Waveform distortion rate |
THD<3% |
| Dynamic response (0 to 100% load) |
5%, ≤50ms |
| Display |
LCD |
| Running mode |
Working continously |
| Electrical insulation properties |
2000Vac, 1min |
| Communication interface |
RS485 (optional), it can remote control the start/stop of the inverter and convey the data as below:
1. Input DC current
2. Input DC voltage
3. Output AC current
4. Output AC voltage
5. Power consumption (kWH)
6. Some fault information |
| Protection Function |
Protection |
Input reverse polarity, under voltage, over-voltage, output over-current, short circuit, overheating |
| Colling method |
Fan-cooled |
| Short-circuit protection |
No automatic recovery, need to restart the machine |
| Working Environment |
Noise (1 meter） |
≤50dB |
| Degree of protection |
IP20 (indoor) |
| Working altitude |
≤2000m |
| Working temperature |
-25~+55℃ |
| Relative humidty |
0~90%, non-condensing |
| Note |
The above parameters are for reference only, can be customized according to customer's requirement! |
Tips:
The conversion efficiency of photovoltaic solar off grid inverters refers to the efficiency of the inverters in converting the electricity from solar panels into electricity. Solar inverters play the role of converting direct current from solar panels into alternating current, and transmitting these alternating currents to the power grid. If the off grid inverters' conversion efficiency is high, the power supply for the use of the inverters will be increased.
