Overview:
Emergency solar generator with 250 watt pure sine wave or 200 watt modified sine wave AC output. Solar generator can match 60W, 80W, 100W, 120W mobile solar panels, maximum 3A charging input. Portable solar generator can be used for home or camping.
Parameter List:
Model |
ATO-PSG-2001 |
ATO-PSG-2002 |
Input |
Adapter: DC 15V/3A Solar Panel Charging: 40-50W, 18-22V |
USB Output |
2 x USB 5V/2.1A Max 1 x TYPE-C 5-9V/2A Qualcomm Quick Charge 3.0, PD 2.0 1 x USB 5-9V/2A Qualcomm Quick Charge 3.0 |
Battery Capacity |
60000mAh/3.7V 222wh, Lithium battery |
DC Output |
9-12.5V/10A (15A Max) |
AC Output |
250W Sine Wave Output |
200W Modified Sine Wave Output |
Bulb Type |
2W ultra bright LED light with SOS/ Blink mode |
4W ultra bright LED light with SOS/ Blink mode |
Power Indicator |
Led Display |
Operation Temperature |
-10 ℃—+40 ℃ |
Lifecycle |
More than 500 times |
Dimensions (L*W*H) |
240*130*135mm |
213*106*180mm |
Weight |
2.6 kg |
2.2 kg |
Package Include |
1 x Portable Power Supply 1 x 15V/3A Power Adapter 1 x Car Charger 1 x Cigarette Lighter Adapter 1 x User Manual |
QTY / CTN |
3 PCS |
Certification |
CE, FCC, Rohs, PSE, UN38.3, MSDS
|
Warranty |
12 months |
Three Types to Get Charged 200 Watt Emergency Solar Generator:
- Charge through AC wall charger
- Charge from portable solar panel (It is recommended to choose 30W, 40W, 60W, 80W, 100W, 120W foldable solar panel.)
- Charge from your car with a cigarette lighter
Attention: To avoid car battery power loss. Charging this unit through your car cigarette lighter is only available when your car engine is started.
Structure:


Application:

Tips: Why Li-Ion Batteries are Amazing Energy Storage Devices?
Lithium-ion battery (LIB) works similarly to other batteries. The main difference, however, is that the electrodes are not strongly affected by chemical reactions. Lithium ions flow from the negative to the positive when discharging and from the negative to the positive when charging.
The main reason why lithium-ion batteries are so popular is their impressive energy density(100-265 Wh/kg or 250-670 Wh/l, depending on the number of lithium ions the electrodes can hold per unit of surface area). This allows mobile devices to capture power in a very small space. Compared to other battery technologies, such as nickel-cadmium or nickel-metal hybrid batteries, lib cells have a short charge time and can run a large number of discharge cycles before being exhausted.
Future power grids are likely to rely on energy storage systems based on lithium-ion batteries. As more and more people adopt energy storage systems combined with rooftop solar, lib may lead to an increase in energy dispersion.
