30kW Three Phase Grid Tie Solar Inverter

Best 30kW on grid tie solar inverter converts 200-820V DC to 3 phase 208V-480V output voltage, supports 2 high efficiency MPPT tracking inputs, transformerless design, LCD display, easy to view and configure, suitable for medium or large-scale grid-tied PV system.
SKU: ATO-GTI-30k
Delivery date: 6-12 days
*
*
$4,312.47
Products specifications
Attribute name Attribute value
Installation Guide

PDFThree-phase Grid Tie Inverter Installation Guide

User Manual

PDFThree-phase Grid Tie Inverter User Manual

Competitive price pure sine wave 30kW grid tie solar inverter used in 50Hz/60Hz low frequency circuit, with wide input voltage range, max DC input voltage up to 850V, three phase 240 volt, 380 volt, 480 volt output voltage, high efficient MPPT more than 99%, more stable and reliable for your on grid solar system.

Features

  • Can be applied to various fields, mainly for solar power, wind power, battery power, and scenery lamp power.
  • Strong IP65 protection, completed sealed cover suitable for harsh environment.
  • Advanced MPPT tracking technology, wide MPPT voltage range.
  • No isolation transformer H6 full-bridge configuration, highest efficiency reach 98%.
  • Over voltage, short circuit, overload, overheating, anti-islanding protection etc.
  • Multiple inverters can be operated in parallel.
  • LCD display, convenient for user to monitor main parameters.
  • Support various communication modes.

Parameter List

MODEL ATO-LTC30000
DC INPUT Max. DC Input Power 32000 watt
Max. DC Input Voltage 850V DC
Max. DC Input Current 90A
MPPT Tracking Voltage Range 200-820V
MPPT Tracking Number / Each Input String Number 1
Power ON / OFF Voltage 200V / 300V
Input Terminal MC4
AC OUTPUT Power 30kW
Output Voltage Default AC 3-phase 380V±5%, (Optional: 208V, 240V, 460V, 480V with ±5% tolerance)
Frequency 50Hz / 60Hz
Phase 3 phase 4 line (3L+N+PE)
Power Factor 0.9
Maximum Current 45A
Current THD At rated power and in the sine wave <3.5%
Max. Efficiency 98.6%
MPPT Efficiency 99.5%
Output Terminal Connect terminals
STRUCTURE Protection Degree IP65
Cooling Method Cooling fan
Topology No transformer
Noise <50db
Data Interfaces RS 485C / RS232 (Standard) / WiFi Module (Optional)
Isolation Type Non-isolated
Standby Power Consumption <5W
Display LCD dispaly
DC Switch Integration
AC Switch Integration
Protection Functions DC input switch, Anti-island, Output over-current, Input reverse connection, DC/AC surge protection, Insulation resistance testing, RCD testing, Upgrade WiFi,
Flexible solar panel
ENVIRONMENT Operation Temperature Air Flow, -10℃~40℃
Storage Temperature -20℃~60℃
Relative Humidity 0~100%
Altitude 2000m, max 3000m
OTHERS Size (W*H*D) 550*850*260mm
Weight 105kg
Certificate CE / G83 / IEC / TUV / SAA
Warranty 5 years

Tips: How to select a right grid tie inverter?

Selecting the correct solar grid tie inverter will increase your solar system efficiency due to its important role, it consisted as the brain of the whole solar system and here are some factors to be well considered:

Efficiency: Try to select the grid tie inverter efficiency to be closer to 100%, in the market you will find efficiencies in the range (96-99%). Efficiency percentage value represents how much energy to be lost during converting DC power to AC power.

Installation: Try to select the grid tie string inverter with simple and easy installation, the inverter should have brackets and all accessories to assist only one person to install. It will be great if the inverter can be installed behind the string modules, so can reduce connection cable length, and save some costs. Also, if the string inverter can be wired via single MC4 to be something like plug and play installation. Just we need to streamline installation process so reduce time and cost.

Inverter connectivity: This is a smart feature that allow you to connect the grid tie string inverter to the internet, then be able to know inverter output and system generation and many other parameters from your PC. This system will provide alarms in case of unnormal conditions like exceeding inverter temperature threshold, and so on. So, you will be able to fully monitor and control your whole solar system remotely via the string inverter connectivity feature. In addition, the inverter connectivity system will store information, so you can recall and revise any historical data that assist you well understanding your system previous problems, productions data, ...then achieving optimal operation and correct planning for the future.

Competitive price pure sine wave 30kW grid tie solar inverter used in 50Hz/60Hz low frequency circuit, with wide input voltage range, max DC input voltage up to 850V, three phase 240 volt, 380 volt, 480 volt output voltage, high efficient MPPT more than 99%, more stable and reliable for your on grid solar system.

Features

  • Can be applied to various fields, mainly for solar power, wind power, battery power, and scenery lamp power.
  • Strong IP65 protection, completed sealed cover suitable for harsh environment.
  • Advanced MPPT tracking technology, wide MPPT voltage range.
  • No isolation transformer H6 full-bridge configuration, highest efficiency reach 98%.
  • Over voltage, short circuit, overload, overheating, anti-islanding protection etc.
  • Multiple inverters can be operated in parallel.
  • LCD display, convenient for user to monitor main parameters.
  • Support various communication modes.

Parameter List

MODEL ATO-LTC30000
DC INPUT Max. DC Input Power 32000 watt
Max. DC Input Voltage 850V DC
Max. DC Input Current 90A
MPPT Tracking Voltage Range 200-820V
MPPT Tracking Number / Each Input String Number 1
Power ON / OFF Voltage 200V / 300V
Input Terminal MC4
AC OUTPUT Power 30kW
Output Voltage Default AC 3-phase 380V±5%, (Optional: 208V, 240V, 460V, 480V with ±5% tolerance)
Frequency 50Hz / 60Hz
Phase 3 phase 4 line (3L+N+PE)
Power Factor 0.9
Maximum Current 45A
Current THD At rated power and in the sine wave <3.5%
Max. Efficiency 98.6%
MPPT Efficiency 99.5%
Output Terminal Connect terminals
STRUCTURE Protection Degree IP65
Cooling Method Cooling fan
Topology No transformer
Noise <50db
Data Interfaces RS 485C / RS232 (Standard) / WiFi Module (Optional)
Isolation Type Non-isolated
Standby Power Consumption <5W
Display LCD dispaly
DC Switch Integration
AC Switch Integration
Protection Functions DC input switch, Anti-island, Output over-current, Input reverse connection, DC/AC surge protection, Insulation resistance testing, RCD testing, Upgrade WiFi,
Flexible solar panel
ENVIRONMENT Operation Temperature Air Flow, -10℃~40℃
Storage Temperature -20℃~60℃
Relative Humidity 0~100%
Altitude 2000m, max 3000m
OTHERS Size (W*H*D) 550*850*260mm
Weight 105kg
Certificate CE / G83 / IEC / TUV / SAA
Warranty 5 years

Tips: How to select a right grid tie inverter?

Selecting the correct solar grid tie inverter will increase your solar system efficiency due to its important role, it consisted as the brain of the whole solar system and here are some factors to be well considered:

Efficiency: Try to select the grid tie inverter efficiency to be closer to 100%, in the market you will find efficiencies in the range (96-99%). Efficiency percentage value represents how much energy to be lost during converting DC power to AC power.

Installation: Try to select the grid tie string inverter with simple and easy installation, the inverter should have brackets and all accessories to assist only one person to install. It will be great if the inverter can be installed behind the string modules, so can reduce connection cable length, and save some costs. Also, if the string inverter can be wired via single MC4 to be something like plug and play installation. Just we need to streamline installation process so reduce time and cost.

Inverter connectivity: This is a smart feature that allow you to connect the grid tie string inverter to the internet, then be able to know inverter output and system generation and many other parameters from your PC. This system will provide alarms in case of unnormal conditions like exceeding inverter temperature threshold, and so on. So, you will be able to fully monitor and control your whole solar system remotely via the string inverter connectivity feature. In addition, the inverter connectivity system will store information, so you can recall and revise any historical data that assist you well understanding your system previous problems, productions data, ...then achieving optimal operation and correct planning for the future.

Products specifications
Attribute name Attribute value
Installation Guide

PDFThree-phase Grid Tie Inverter Installation Guide

User Manual

PDFThree-phase Grid Tie Inverter User Manual

Existing reviews
Intelligent 30kW 3 phase grid tie solar inverter
I like this 30kW 3 phase grid tie solar inverter very much because it is very smart. Whenever it gets hot, the fan starts running and switches off again when cooled down. To prevent it from overheating and damaging the machine.
